Extreme Networks ExtremeSwitching VSP4900 24-port Switch
Simplify Your Network with an Extreme Fabric Connect Multi-service Edge Device

Extreme Networks VSP4900 24-port Switch

Extreme Networks Products
Virtual Services Platform 4900 Series
VSP 4900 System with 24 x 100/1000BASE-X ports
Includes 3 fan modules, 4 post rack mount kit, VOSS operating system (PSU must be ordered separately)
#VSP4900-24S
Our Price: $10,499.00
VSP 4900 System with 24 x 1/10GBASE-X SFP+ MACsec and LRM-capable ports
Includes 3 fan modules, 4 post rack mount kit, VOSS operating system (PSU must be ordered separately)
#VSP4900-24XE
Our Price: $20,187.00
Call For Lowest Price!
VSP 4900 System with 12 x 1/2.5/5/10G0GBASE-T 802.3bt PoE (60W) ports and 12 x 1/10GBASE-X SFP+ MACsec-capable ports
Includes 3 fan modules, 1 unpopulated VIM5 slot, 4 post rack mount kit, VOSS operating system (PSU must be ordered separately)
#VSP4900-12MXU-12XE
Our Price: $19,515.00
Call For Lowest Price!
Virtual Services Platform 4900 Series Bundle
VSP 4900 System with 24 x 100/1000BASE-X ports and 350W PSU Bundle
Includes 3 fan modules, 1 x 350W PSU (10953), 4 post rack mount kit, VOSS operating system
#VSP4900-24XE-B3
Our Price: $21,171.00
Call For Lowest Price!
VSP 4900 System with 12 x 1/2.5/5/10G0GBASE-T 802.3bt PoE (60W) ports, 12 x 1/10GBASE-X SFP+ MACsec-capable ports and 1100W PSU Bundle
Includes 3 fan modules, 1 unpopulated VIM5 slot, 1 x 1100W PSU FB (10941), 4 post rack mount kit, VOSS operating system
#VSP4900-12MXU-12XE-B1
Our Price: $21,171.00
Call For Lowest Price!

Click here to jump to more pricing!

Overview:

The Virtual Services Platform (VSP) 4900 Series is the next generation of Extreme Fabric Connect fixed-form factor switches designed for network edge and aggregation deployments. Providing high-performance, resilient and secure Gigabit/multi-Gigabit Ethernet connectivity, the VSP 4900 enables end-to-end fabric services from network edge to aggregation to core, along with transparent extension of fabric services to the branch. Its advanced capabilities enable full-featured network virtualization to be flexibly deployed across a range of network environments.

The VSP 4900 Series is available in four model variants to address a range of campus, remote site and/or multi-service needs.

  • VSP4900-48P: 48 x 10/100/1000MbE with 30W PoE+ and MACseccapable ports
  • VSP4900-24S: 24 x 1G SFP ports
  • VSP4900-24XE: 24 x 1/10GbE SFP+ MACsec (256-bit) capable ports
  • VSP4900-12MXU-12XE: 12 x 100M/1G/2.5G/5G/10GbE ports with 60W PoE, plus 12 x 1/10GbE SFP+ MACsec (256-bit) capable ports

All models above also support modular uplinks – at 10Gb, 25Gb and 40Gb – for flexible linkage to other switches or devices over a range of media.

Highlights

  • Fixed-form switch for virtualized branch and network edge applications
  • Leverages Extreme Fabric Connect to simplify the network, while helping segment traffic to meet regulatory/ security needs
  • Native Fabric Extend support enables transparent extension of Fabric Connect services over 3rd-party networks
  • Multiple models supporting 1GbE 30W PoE, 1Gb/10GbE SFP/SFP+ fiber and 1/2.5/5/10GbE multi-rate 60W PoE access ports
  • Flexible 10Gb/25Gb/40Gb inter-switch or uplinks via optional VIM modules
  • Compact 1U form factor
  • Non-blocking, wire-speed switching architecture
  • Extreme Insight Architecture on selected models to support VM-based third-party applications
  • MACsec on 10/100/1000 and 10Gb access ports as well as modular uplink ports for secure link encryption
  • Hot-swappable, redundant power supplies and fans
  • Supports both Fabric Connect and/ or onventional Routed IP networking deployments

Features:

Extreme Fabric Connect

The VSP 4900 natively supports the Extreme Fabric Connect technology. Based on an extended implementation of the Shortest Path Bridging (SPB) standards of IEEE 802.1aq and IETF RFC 6329, Fabric Connect offers the ability to create a virtualized network that simplifies network provisioning and reduces the strain on network and IT personnel.

Fabric Connect features supported on the VSP 4900 Series include: L2 Virtual Service Networks (VSNs), Layer 3 Virtual Service Networks, Inter-VSN Routing, IPv4/ IPv6 IP Shortcuts, IP Multicast over Fabric Connect, Fabric Extend and Fabric Attach Server.

Fabric Extend

The VSP 4900 also natively supports Fabric Extend that enables it to extend Fabric Connect services over an intermediate 3rd-party network -- whether Layer 2 or Layer 3-based. With Fabric Extend, enterprises can, for example, connect two Fabric Connect environments (or islands) over a Service Provider WAN, such as MPLS or Ethernet WAN. Fabric Connect simplified provisioning and virtualization services can then be transparently extended across the 3rdparty network.

Advanced Layer 3 Services

The VSP 4900 Series also supports advanced Layer 3 services that enable it to satisfy conventional IP routing deployments, in addition to its fabric-based services. Layer 3 services include IPv4 and IPv6 dynamic routing, as well as IP multicast services.

Specific IP routing technologies supported include RIPv1/2, RIPng, OSPFv2/v3, BGP/ BGP+ and VRF. Multicast services include PIM-SM/ SSM, IGMP v1/v2/v3, as well as Fabric Connect to PIM gateway. The VSP 4900 also supports Distributed Virtual Routing (DvR) leaf services.

Power Over Ethernet

VSP 4900-48P and VSP 4900-12MXU-12XE models offer Power over Ethernet (PoE) to address the needs of powered edge devices. The VSP 4900-48P supports IEEE 802.3at (30W) PoE on its 48 x 1Gb ports; and the VSP 4900-12MXU-12XE supports IEEE 802.3bt (60W) PoE on its 12 multi-rate ports. Both VSP 4900 models also support fast PoE and perpetual PoE capabilities for faster start-up and more continuous operation of connected, PoE-powered end-points.

Extreme Insight Architecture

Extreme's Insight Architecture leverages an innovative combination of VSP 4900 Series operating software and hardware features to provide extended services without impact to switching or network performance. Available on VSP4900-12MXU-12XE and VSP4900-24XE models, this flexible and open solution enables organizations to run a Guest VM on the VSP 4900 system. Organizations can then use the Guest VM to deploy their choice of Extremeprovided or third-party application/tools for real-time visibility or to meet specific business or operational needs across the network. This can help improve network visibility and performance, while reducing operational costs.

MACsec Link Encryption

The VSP 4900 supports IEEE 802.1AE MACsec on its access ports, as well as on its modular uplink ports. MACsec is a hop-by-hop security capability which encrypts/ decrypts packets between connected switches or devices. As a link-only encryption, the switches can still apply services to the packet, such as policy or QoS, without compromising the security of packets across the link. With support for both 128-bit and 256-bit Advanced Encryption Standard (AES) support, the VSP 4900 provides the most secure link encryption.

VIM Options for Flexible Uplinks

The VSP 4900 supports Versatile Interface Modules (VIM) for its uplink ports and has a single VIM slot that can be optionally used for this purpose. VIM options include 2 and 4-port modules that support 10Gb, 25Gb and 40Gb data rates.

Management

The VSP 4900 can be managed in a variety of ways. Simple on-box management functions are delivered by a web-based GUI and a generic CLI is available for manual configuration.

ExtremeCloudTM IQ along with Extreme Management Center (XMC) also provide a comprehensive unified management capability with a consolidated view of users, devices and applications for both wired and wireless networks. Remote provisioning lets one quickly bring new VSP 4900 switches online and a granular view of devices ports and users enables efficient inventory and network topology management.

Specifications:

  VSP4900- 12MXU-12XE VSP4900-24XE VSP4900-24S VSP4900-48P
Performance and Scaling
Max Active 10/100/ 1000Mb Ports N/A 0 0 48
Max Active 100M/1Gb/ 2.5Gb/5Gb/ 10Gb Ports 12 0 0 0
Max Active 100M/1Gb SFP ports 0 24 0 0
Max Active 1/10Gb SFP+ ports 16 28 4 4
Max Active 10/ 25Gb SPF28 ports 4 4 2 2
Max Active 40Gb QSFP+ ports* 2 2 1 1
Aggregated Switch Bandwidth 680 Gbps 680 Gbps 148 Gbps 196 Gbps
Frame Forwarding Rate 505.9 Mpps 505.9 Mpps 110.1 Mpps 145.8 Mpps
External Ports/Slot
Ports/Slots
  • 12 x 1/2.5/5/10GBASE-T 802.3bt Type3 (60w) ports
  • 12 x 1/10GBASE-X SFP+ ports (unpopulated)
    • MACsec capable (256-bit)
  • 1 x Serial (console port RJ-45)
  • 1 x 10/100/1000BASE-T out-of-band management port
  • 1 x USB Micro-B management port
  • 2 x USB A ports for external USB flash
  • 1 VIM5 slot
  • 24 x 1/10GBASE-X SFP+ ports (unpopulated)
    • LRM and MACsec capable (256-bit)
  • 1 x Serial (console port RJ-45)
  • 1 x 10/100/1000BASE-T out-of-band management port
  • 1 x USB Micro-B management port
  • 2 x USB A ports for external USB flash
  • 1 VIM5 slot
  • 24 x 100/1000BASE-X SFP ports (unpopulated)
  • 1 x Serial (console port RJ-45)
  • 1 x 10/100/1000BASE-T out-of-band management port
  • 1 x USB Micro-B management port
  • 2 x USB A ports for external USB flash
  • 1 VIM5 slot
  • 48 x 10/100/1000BASE-T 802.3at (30w) ports
    • Full / Half-Duplex
    • MACsec capable (128-bit)
  • 1 x Serial (console port RJ-45)
  • 1 x 10/100/1000BASE-T out-of-band management port
  • 1 x USB Micro-B management port
  • 2 x USB A ports for external USB flash
  • 1 VIM5 slot
VIM Modules
VIM Modules
  • VIM5-4X: 4 x 1/10GBASE-X SFP+ (unpopulated ports)
  • VIM5-4XE: 4 x 1/10GBASE-X SFP+ (unpopulated ports)
    • LRM capable
    • MACsec capable (256-bit)
  • VIM5-2Y: 2 x 10/25GBASE-X SFP28 (unpopulated ports)
  • VIM5-4Y: 4 x 10/25GBASE-X SFP28 (unpopulated ports)
  • VIM5-4YE: 4 x 10/25GBASE-X SFP28 (unpopulated ports)
    • MACsec capable (256-bit)
  • VIM5-2Q: 2 x 40GBASE-X QSFP+ (unpopulated ports)
Physical Specifications
Dimensions 17.34 in W / 1.7 in H / 19.23 in D
440mm / 43.6mm / 488mm
17.34 in W / 1.7 in H / 19.23 in D
440mm / 43.6mm / 488mm
17.34 in W / 1.7 in H / 19.23 in D
440mm / 43.6mm / 488mm
17.34 in W / 1.7 in H / 19.23 in D
440mm / 43.6mm / 488mm
Net Weight 16.67 lb / 7.58 kg 16.89 lb / 7.66 kg 18.01 lb / 8.17 kg 18.49 lb / 8.39 Kg
Minimum/Maximum Power Consumption and Heat Dissipation
Minimum Power Consumption (Watts) 73 80 52 74
Minimum Heat Dissipation (BTU/hr) 250 271 179 254
Maximum Power Consumption (Watts)1 970 207 173 1746
Maximum Heat Dissipation (BTU/hr)2 854 707 590 1046


Performance and Scale

  • Memory
    • VSP4900-48P and VSP4900-24S
      • 2GB DRAM / 8GB eMMC NVRAM
    • VSP4900-12MXU-12XE and VSP4900-24XE
      • 8GB DRAM / 8GB eMMC NVRAM
  • Layer 2
    • MAC Address: up to 80,000
    • Port-based VLANs: 4,059
    • MSTP Instances: 12
    • LACP Links per Group: 8 Active
  • Layer 3 IPv4 Routing Services
    • ARP Entries: up to 32,000
    • IP Routes: up to 15,488
    • RIP Interfaces: 200
    • OSPF Interfaces: 500
    • BGP Peers: 256
    • VRF Instances: up to 256
    • Layer 3 IPv6 Routing Services
    • Neighbors: up to 8,000
    • IP Routes: up to 7,744
    • RIPng Interfaces: 48
    • OSPFv3 Interfaces: 500
    • BGPv6 Peers: 256
    • VRF Instances: up to 256
  • Multicast
    • IGMP Interfaces: 4,059
    • PIM Active Interfaces: 128
    • MLD Interfaces: 4,059
    • IP Multicast Streams: 6,000
  • Fabric Connect
    • MAC Address: 40,000
    • NNI Interfaces/Adjacencies: up to 255
    • BEB Nodes per VSN: 500
    • BCB/ BEB Nodes per Region: 550
    • L2 Virtual Service Networks: 4,059
    • L3 Virtual Service Networks: up to 256
    • IP Shortcut Routes: IPv4 up to 15,488 and IPv6 7,488
    • L2 Multicast Virtual Service Networks: 2,000
    • L3 Multicast Virtual Service Networks: 256
    • Maximum SGVs: 6,000
  • QoS and Filtering
    • IPv4 ACE: 1536 (1024 Security + 512 QOS) Ingress and 248 Egress
    • IPv6 ACE: 1024 Ingress and 256 Egress
    • QoS priority queues- 8
  • Operations and Management
    • Mirrored Ports: 49
    • sFlow: up to 3100 samples per second
    • Fabric RSPAN: 1,000 VLAN IDs

Environmental

  • Environmental Specifications
    • EN/ETSI 300 019-2-1 v2.1.2 - Class 1.2 Storage
    • EN/ETSI 300 019-2-2 v2.1.2 - Class 2.3 Transportation
    • EN/ETSI 300 019-2-3 v2.1.2 - Class 3.1e Operational
    • EN/ETSI 300 753 (1997-10) - Acoustic Noise
    • ASTM D3580 Random Vibration Unpackaged 1.5 G
  • Environmental Compliance
    • EU RoHS 2011/65/EU
    • EU WEEE 2012/19/EU
    • China RoHS SJ/T 11363-2006
    • Taiwan RoHS CNS 15663(2013.7)
  • Operating Conditions
    • Temp: 0° C to 45° C (32° F to 113° F)
    • Humidity: 10% to 95% relative humidity, non-condensing
    • Altitude: 0 to 3,000 meters (9,850 feet)
    • Shock (half sine) 30m/s2 (3G), 11ms, 60 shocks
    • Random vibration: 3 to 500 Hz at 1.5 G rms
  • Packaging and Storage Specifications
    • Temp: -40° C to 70° C (-40° F to 158° F)
    • Humidity: 10% to 95% relative humidity, non-condensing
    • Packaged Shock (half sine): 180 m/s2 (18 G), 6 ms, 600 shocks
    • Packaged Vibration: 5 to 62 Hz at velocity 5 mm/s, 62 to 500 Hz at 0.2 G
    • Packaged Random Vibration: 5 to 20 Hz at 1.0 ASD w/–3 dB/oct. from 20 to 200 Hz
    • Packaged Drop Height: 14 drops minimum on sides and corners at 42 inches (<15 kg box)

Regulatory and Safety

  • North American ITE
    • UL 60950-1
    • UL 62368-1
    • Complies with FCC 21CFR 1040.10 (U.S. Laser Safety)
    • CDRH Letter of Approval (US FDA Approval)
    • CAN/CSA 22.2 No. 60950-1
    • CAN/CSA No. 22.2 62368-1-14
  • European ITE
    • EN 60950-1, EN 62368-1
    • EN 60825-1Class 1 (Lasers Safety)
    • 2014 / 35/ EU Low Voltage Directive
  • International ITE
    • CB Report & Certificate per IEC 60950-1 AS/NZS 60950-1 (Australia /New Zealand)
    • IEC 62368-1
    • GB 4943.1-2011
    • CNS 14336-1

EMI/EMC Standards

  • North American EMC for ITE
    • FCC CFR 47 part 15 Class A (USA)
    • ICES-003 Class A (Canada)
  • European EMC Standards
    • EN 55032 Class A
    • EN 55024
    • EN 55035
    • EN 61000-3-2,2014 (Harmonics)
    • EN 61000-3-3 2013 (Flicker)
    • EN 300 386 v1.6.1 (EMC Telecommunications)
    • 2014/30/EU EMC Directive
    • EN 55011 Class A
  • International EMC Certifications
    • CISPR 32, Class A (International Emissions)
    • AS/NZS CISPR32
    • CISPR 24 Class A (International Immunity)
    • IEC 61000-4-2 / EN 61000-4-2 Electrostatic Discharge, 8kV Contact, 15 kV Air, Criteria A
    • IEC 61000-4-3 /EN 61000-4-3 Radiated Immunity 10V/m, Criteria A
    • IEC 61000-4-4 / EN 61000-4-4 Transient Burst, 1 kV, Criteria A
    • IEC 61000-4-5 /EN 61000-4-5 Surge, 2 kV L-L, 2 kV L-G, Level 3, Criteria A
    • IEC 61000-4-6 Conducted Immunity, 0.15-80 MHz, 10V/m unmod. RMS, Criteria A
    • IEC/EN 61000-4-11 Power Dips & Interruptions, >30%, 25 periods, Criteria C
    • IEC 61000-4-8 / EN 61000-4-8
    • CISPER 11 Class A
    • GB/T 9254-2008
  • Country Specific
    • VCCI Class A (Japan Emissions)
    • ACMA RCM (Australia Emissions)
    • CCC Mark (China)
    • KCC Mark, EMC Approval (Korea)
    • EAC Mark (Custom Union)
    • NRCS / ICASA Mark (South Africa)
    • BSMI Mark (Taiwan)
  • Telecom Standards
    • CE 2.0 Compliant

IEEE 802.3 Media Access Standards

  • IEEE 802.3ab 1000BASE-T
  • IEEE 802.3ae 10GBASE-X
  • IEEE 802.3aq 10GBASE-LRM
  • 25Gb Ethernet implemented per Ethernet Consortium specification and IEEE 802.3 standard
  • IEEE 802.3ba / 802.3bm 40GBASE-X
  • IEEE 802.3at PoE Plus
  • IEEE 802.3az Energy Efficient Ethernet

* 40Gb ports on the VIM5 module can also be broken out individually into 4 x 10Gb ports.
1 Includes maximum PoE load (W) through the switch
2 Does not include PoR load heat dissipated through external electronic load

Power Supply Unit Specifications:


  350W AC PSU 715W AC PSU 1100W AC PSU 2000W AC PSU
Voltage Input Range (nominal) 100-127 / 200-240VAC 100-127 / 200-240VAC 100-127 / 200-240VAC 100-127 / 200-240VAC
Line Frequency Range 47 to 63 Hz 47 to 63 Hz 47 to 63 Hz 47 to 63 Hz
Power Supply Input Socket IEC/EN 60320 C14 IEC/EN 60320 C16 IEC/EN 60320 C16 IEC/EN 60320 C16
Power Cord Input Plug IEC/EN 60320 C13 IEC/EN 60320 C15 IEC/EN 60320 C15 IEC/EN 60320 C15
Operating Temperature 0˚ to 50˚C normal operation 0˚ to 50˚C normal operation 0˚ to 50˚C normal operation 0˚ to 45˚C normal operation

  VSP4900-12MXU-12XE VSP4900-48P
1 x 715W PSU TBD 460W
2 x 715W PSU 720W 1045W
1 x 1100W PSU 720W 845W
2 x 1100W PSU 720W 1440W
1 x 2000W @ 200-240VAC 720W 1440W
1 x 2000W @ 100-120VAC 720W 845W
2 x 2000 @ 200-240VAC 720W 1440W
2x 2000W @ 100-120VAC 720W 1440W

Pricing Notes:

Extreme Networks Products
Virtual Services Platform 4900 Series
VSP 4900 System with 24 x 100/1000BASE-X ports
Includes 3 fan modules, 4 post rack mount kit, VOSS operating system (PSU must be ordered separately)
#VSP4900-24S
Our Price: $10,499.00
VSP 4900 System with 24 x 1/10GBASE-X SFP+ MACsec and LRM-capable ports
Includes 3 fan modules, 4 post rack mount kit, VOSS operating system (PSU must be ordered separately)
#VSP4900-24XE
Our Price: $20,187.00
Call For Lowest Price!
VSP 4900 System with 12 x 1/2.5/5/10G0GBASE-T 802.3bt PoE (60W) ports and 12 x 1/10GBASE-X SFP+ MACsec-capable ports
Includes 3 fan modules, 1 unpopulated VIM5 slot, 4 post rack mount kit, VOSS operating system (PSU must be ordered separately)
#VSP4900-12MXU-12XE
Our Price: $19,515.00
Call For Lowest Price!
Virtual Services Platform 4900 Series Bundle
VSP 4900 System with 24 x 100/1000BASE-X ports and 350W PSU Bundle
Includes 3 fan modules, 1 x 350W PSU (10953), 4 post rack mount kit, VOSS operating system
#VSP4900-24XE-B3
Our Price: $21,171.00
Call For Lowest Price!
VSP 4900 System with 12 x 1/2.5/5/10G0GBASE-T 802.3bt PoE (60W) ports, 12 x 1/10GBASE-X SFP+ MACsec-capable ports and 1100W PSU Bundle
Includes 3 fan modules, 1 unpopulated VIM5 slot, 1 x 1100W PSU FB (10941), 4 post rack mount kit, VOSS operating system
#VSP4900-12MXU-12XE-B1
Our Price: $21,171.00
Call For Lowest Price!
VIM Modules
4 x 1G/10G SFP+ VIM supported on VSP 4900
#VIM5-4X
Our Price: $1,683.00
4 x 1G/10G SFP+ LRM and MACsec capable VIM supported on VSP 4900
#VIM5-4XE
Our Price: $2,693.00
4 x 10G/25G SFP28 MACsec capable VIM supported on VSP 4900
#VIM5-4YE
Our Price: $5,384.00
2 x 10G/40G QSFP VIM supported on VSP 4900
#VIM5-2Q
Our Price: $2,693.00
Software Licenses
VSP 4900 Premier Software License: Enables L3 VSNs, > 16 BGP peers, > 24 VRFs and Insight Architecture
#VSP-PRMR-L-LIC-P
Our Price: $5,640.00
VSP 4900 Premier Software License with MACsec; Enables LVSNs, > 16 BGP peers, > 24 VRFs and Insight Architecture
#VSP-PRMR-LE-LIC-P
Our Price: $5,640.00
PHP Warning: PHP Startup: Unable to load dynamic library 'C:\Program Files (x86)\PHP\v5.6.34\ext\php_pdo_sqlsrv.dll' - The specified module could not be found. in Unknown on line 0 PHP Warning: PHP Startup: Unable to load dynamic library 'C:\Program Files (x86)\PHP\v5.6.34\ext\php_sqlsrv.dll' - The specified module could not be found. in Unknown on line 0
